YLCASTER OEM 770LBS Load Capacity Aluminium PU Wheel Top Plate
Heavy Duty Rigid Casters
Description:
This heavy-duty 5 inch directional PU caster can withstand 770 pounds of weight per wheel, and is suitable for various high-load carts. The polyurethane encapsulation wraps the aluminum alloy sturdy wheel core, which is silent, wear-resistant and environmentally friendly, and can effectively protect the floor without leaving traces.
Product Specifications:
770lbs fixed type heavy duty aluminium pu casters
Model Number | Wheel Diameter/Width MM | Overall Height MM | Plate Size MM | Bolt Hole Distance MM | Bolt Hole Size MM | Bearing Type | Loaded Capacity LBS |
I004A125APU2PF | 125x50 | 166 | 115x100 | 85x72 | 20x13 | Double Ball | 770 |
770lbs swivel type heavy duty aluminium pu casters
Model Number | Wheel Diameter/Width MM | Overall Height MM | Plate Size MM | Bolt Hole Distance MM | Bolt Hole Size MM | Bearing Type | Loaded Capacity LBS |
I004A125APU2P | 125x50 | 166 | 115x100 | 85x72 | 20x13 | Double Ball | 770 |
770lbs swivel side lock heavy duty aluminium pu casters
Model Number | Wheel Diameter/Width MM | Overall Height MM | Plate Size MM | Bolt Hole Distance MM | Bolt Hole Size MM | Bearing Type | Loaded Capacity LBS |
I004A125APU2PB1 | 125x50 | 166 | 115x100 | 85x72 | 20x13 | Double Ball | 770 |
About Us:
FAQ:
Q: What is the material of this type casters?
A: These orange side brake heavy duty casters are equipped with
aluminium core and pu tread.
Q: What is the feature of these aluminium pu casters?
A: Durable, silent, high capacity and no-marking.
Q: Is total brake type available?
A: Yes, you can have it.
Q: If i want to stop the wheel, how should i choose the caster?
A: You can choose side brake type or total brake type.
Q: If i don't like the color?
A: No problem, we can change it for you.
Q: If i want to install these type of casters on the platform
trolleys, how should i choose?
A: Usually 2 swivel type and 2 rigid wheels.
![]() |
