5 inch 135kg threaded stem swivel abs arc tread tpr silent medical
casters customize
Description:
1.TPR tread pp core wheel.
2.ABS shells protect bearings.
3.Threaded stem mounting type, top plate/plate, bolt hole, stem
type are also available.
4.Including swivel, fixed/rigid,and swivel brake type.
5.No marking, silent, smelless.
6.Top plate, threaded stem, bolt hole and stem type mounting type
available.And the three mounting type of caster wheels of different
diameter share the same specification. Including top plate, stem
and bolt hole. The plate type are fixed by 4 pcs 8mm diameter
screws with the objects. And the stem one require a 28x45mm size
stem hole to install with. But the threaded stem one are not the
same.
7.Ball bearing rotating construction.
8.Arc tread and flat tread are all available.
Product Specifications:
Threaded Stem Type
| Model Number | Wheel Diameter/Wideth
MM | Overall Height
MM | Threaded Stem Size
MM | Bearing Type | Loaded Capacity
KG |
| M004A075TPRT | 76x32 | 120 | 12x25 | Double Ball Bearing | 90 |
| M004A100TPRT | 101x32 | 149 | 12x25 | 120 |
| M004A125TPRT | 126x32 | 177.5 | 16x30 | 135 |
Stem Type
| Model Number | Wheel Diameter/Wideth
MM | Overall Height
MM | Stem Size
MM | Bearing Type | Loaded Capacity
KG |
| M004A075TPRS | 76x32 | 120 | 28x45 | Double Ball Bearing | 90 |
| M004A100TPRS | 101x32 | 149 | 28x45 | 120 |
| M004A125TPRS | 126x32 | 177.5 | 28x45 | 135 |
Bolt Hole Type
| Model Number | Wheel Diameter/Wideth
MM | Overall Height
MM | Bolt Hole Size
MM | Bearing Type | Loaded Capacity
KG |
| M004A075TPRD | 76x32 | 120 | 13.1 | Double Ball Bearing | 90 |
| M004A100TPRD | 101x32 | 149 | 13.1 | 120 |
| M004A125TPRD | 126x32 | 177.5 | 13.1 | 135 |
Top Plate Type
| Model Number | Wheel Diameter/Wideth
MM | Overall Height
MM | Plate Size
MM | Bolt Hole Spacing
MM | Bolt Hole Size
MM | Bearing Type | Loaded Capacity
KG |
| M004A075TPRP | 76x32 | 120 | 96x63 | 75x45.5 | 12x8.4 | Double Ball Bearing | 90 |
| M004A100TPRP | 101x32 | 149 | 96x63 | 75x45.5 | 12x8.4 | 120 |
| M004A125TPRP | 126x32 | 177.5 | 96x63 | 75x45.5 | 12x8.4 | 135 |
Note: Flat tread type are also available
FAQ:
Q: Are you manufacture or trading company?
A: We are caster wheels manufacturer. Our factory has been
specializing in all kinds of caster wheels since 1997.
Q: Where is your factory? Can I visit ?
A: Our factory is located in Yangjiang, Guangdong. 2 hours by car
from Guangzhou,You are warmly welcome to visit whenever you are
available.
Q: What is your delivery time?
A: In general, within 20 days. It also depends on the order
quantity.
Q: What is the term of payment?
A: Payment terms: 30% of deposit upon signing the PI, and balance
will be cleared by T/T or L/C before delivery.
Q: Are samples available?
A: Yes, samples are available at any time, negotiable.
Q: Can i customize my own logo/brand? If i want to make a new type
of caster, is that possible?
A: Yes, my friend. You can print your brand logo on the packing
box, aslo can punching logo on the caster bracket, even produce
your new model of caster with our great professional experience. We
are good at doing the OEM things.
